UBE4100 Product Singulator
Takes product arriving in a mass and hands it on one at a time, correctly spaced, without marking it. The machine most capacity problems turn out to need.
Why it is specified
- Separates without pinching, so soft and just-cooled product is not marked
- Output spacing is set to what the next machine wants, not to a fixed pitch
- Absorbs surge from upstream instead of passing it to the wrapper
Runs for
How it works
Separated, not pinched
Product is separated by differential speed rather than by squeezing it between belts. Soft and just-cooled product comes through unmarked.
Spacing to order
Output pitch is set to what the next machine wants. A singulator that hands on at its own convenience just moves the problem downstream.
Surge absorbed here
Short surges from upstream are taken up rather than passed on. The wrapper sees a steady stream, which is all it ever wanted.
Specifications
| Specification | UBE4100 |
|---|---|
| Throughput | to 400 pieces/min |
| Product size | 40 – 250 mm |
| Output pitch | Adjustable, 60 – 400 mm |
| Belt material | FDA blue, food grade |
| Connected load | 2.0 kW |
Separation quality depends on product tack. Figures are for cooled product at ambient.
Next step
Specify the UBE4100 Product Singulator for your line
Tell us the product, the rate you need and what the machine has to fit between. We come back with a configuration, a footprint and a lead time.
