90-75 Band Slicer
Bread | Hearth Bread | Pullman Loaf | Cake | Raisin Bread
90-75 Band Slicer
The UBE Model 90-75 Band Slicer combines years of step-by-step improvements into a servo driven reciprocating bagger with fewer moving parts and increasing reliability at high speed.
UBE builds the Model 90-75 Band Slicer for each customer’s particular needs. Over 1000 installations required numerous customer driven innovations. Your machine may vary from this typical unit illustrated. UBE wants to meet with you and design your new line.
FEATURES & SPECIFICATIONS
-
Adjusting Unit Range/Standard: 3/8” to 5/8”; [9.5mm to 15.9mm]
-
Blade speed: 1020 ft/min [25.9m/min]
-
Maximum Product Length: 16”L x 6”H x 10”W; [432mm x 152mm x 254mm]
-
Slicing speed: Up to 90 Loaves Per Minute
-
BISSC Approved
-
Category 3 Safety Compliant with Dual Channel Switches, Safety Relay, and VFD
-
Drum Scrapers Crumb Build-Up
-
Last Loaf Ejector
-
Single Point Infeed and Outfeed Rail Adjustments
-
Stainless Steel Frame Features Paint-Free Construction and Easy-Access Guarding
-
Optional Caustic Washdown Construction
-
Optional Extra-Long Loaf Capacity
-
Optional Heel Remover
-
Optional Oil Spray Kit
-
Optional Refrigerated Drums
-
Optional Washdown Construction
-
Blade Length: 176” or 184” [4.47m - 4.49m]
-
Electrical: 230/380/460 Volt, 50/60 Hz, 3 Ph, 5 HP
-
Minimum Product Width: 6”L x 2”H x 3”W; [152mm x 51mm x76mm]
-
Automatic Broken Blade Shut Off
-
Blade guides are offset to eliminate build-up
-
Connects to all Baggers and Wrappers
-
Integration Compatibility with Any Brand Packaging Machine
-
Painted Electrical Enclosure IP65 (NEMA 12) Rated
-
Slice Thickness Adjusting Mechanism Easily Removed for Wash-Down Cleaning
-
Optional Automatic Blade Hone
-
Optional Custom Slice Thicknesses
-
Optional Hearth Bread Kit
-
Optional Metric Construction
-
Optional Raisin Bread Kit
-
Optional Splitter Turner for Half Loafs
-
Optional Washdown Construction
