10 Band Slicer
Bread | Hearth Bread | Pullman Loaf

10 Band Slicer

The Model 10 slicer is built with a minimum of parts and simple logic. It is the perfect band slicer for the smaller producer that need a higher capacity than what a Oliver slicer or other table top slicers can produce.

UBE builds the Model 10 Band Slicer for each customer’s particular needs. Over 1000 installations required numerous customer driven innovations. Your machine may vary from this typical unit illustrated. UBE wants to meet with you and design your new line.


  • Painted electrical enclosure IP65 Stainless steel frame features paint free construction and easy access guarding
  • Ceramic blade guides fixed for desired slice thickness
  • Adjustable loaf guides
  • Hand bag loader integrated with slicer
  • Automatic broken blade shutoff
  • Slicing speed (per minute) 5 to 15 loaves, depending on type and size
  • Electrical enclosure IP 65 (NEMA 12) rated
  • Powered in-feed and out-feed conveyors
  • Last loaf pusher
  • Category 3 Safety Compliant with Dual Channel Switches, Safety Relay, and VFD
  • Painted electrical enclosure IP65 (Nema 12) rated
  • Slicer thickness (fixed) 3/8” to 5/8” [9.5 to 16mm] Other ranges available


Specifications vary by product and application. Please contact our sales office about product varieties and speeds.

  • Electrical
    • 208/230/380/460 V - 3 Phase, 50/60 Hz
  • Minimum Product Width
    • 3”
  • Maximum Product Length
    • 16”
  • Blade size
    • 130” x .012” x 7/16” [3302 x .3 x 11.12mm]
Machine Options:
  • Manual blade sharpener
  • Spray oiling system
  • Stainless steel electrical enclosure IP 66 (NEMA4) rated
  • UBE 800 slicer feed roller conveyor
  • UBE 14-C bag closing conveyor
  • Kwik Lok or Burford bag closing machine
  • CE Approval, guards and coded magnetic door switches
  • UL Approval
  • CSA/UL Approval
  • Available in metric construction (where possible)
